Description
LogicMachine 5 Lite
Logic Machine5 Lite acts as cross-standard gateway, cloud service integrator, complex network logic engine, easy-to create visualization platform, IP Router and much more. Further, LM5 supports iOS Siri and Google Voice control via native apps available in App Store and Google Play.
LogicMachine 5 Lite is the basic module of all LogicMachine5 Reactor devices, so the difference if only in physical ports.
Hightlights
- Power-over-Ethernet powering
- Automatic Ethernet connection checking and informing in case of troubles
- Application development and application store
- Cloud ready device with Microsoft Azure, Amazon Web Services and other services supported
- Gateway and uniform way of control of KNX, ModBus RTU/TCP, BACnet IP, DMX, M-Bus, GSM and more
- Unlimited scenario and logic engine
- Unlimited visualization platform for PC and for touch devices
- Size: 3 DIN units
- Remote KNX bus control and KNX device reprogramming
- Object logging with trends support and data exporting to external servers
- Amazon Echo, Apple HomeKit, Google Home supported via native apps
- 3x more powerful CPU than all previous LogicMachine versions.
See CPU comparison tests here
LogicMachine5 comparison table 1.2024
LogicMachine core functionality presentation
I/O specification
- 1 x RS485
- 1 x RS485/RS-232 (switchable in software)
- 1 x USB2.0 (starting from 9.2016)
- 1 x 10/100 Ethernet with passive PoE support
- 1 x KNX TP1 (TP-UART2 physical layer IC)
- 1 x USB2.0
Standards and protocols
Download LogicMachine5 Lite Power Datasheet here
Download LogicMachine5 Lite Manual here
Demo LogicMachine5
Demo device can be found here (admin / admin)
Visualization examples
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
