WEINZIERL 732 KNX IP Interface secure Interface between LAN and KNX bus

SKU: 5248 Category: Tag:

KNX IP INTERFACE 732 SECURE

Description

The KNX IP Interface 732 secure serves as a secure interface between a LAN (IP, Ethernet) and KNX and can be used as a programming interface for the ETS®. As a KNX Secure Interface (tunneling), the device prevents unauthorized access to the system. The connection between PC and interface is encrypted. The security option can be activated or deactivated in the ETS.

With the KNX IP Interface 732 secure, the KNX bus can be accessed from any point in the LAN. Encryption also enables secure programming over the Internet.

The device is characterized by a compact design with a width of only 1 module width (18 mm) and is powered by the KNX bus.

The buttons and LEDs on the device allow a local diagnosis of the current operating status and possible communication errors.

Knx_Ip_Interface_732_Secure_Picture

TECHNICAL DATA

Mechanical Data

  • Housing: plastic
  • DIN rail mounted device
  • Width: 1 module (18 mm)

Controls and indicators

  • 2 buttons and 3 LEDs, multicolor
  • KNX programming button with LED (RD)

Ethernet

  • 100BaseT (100MBit/s)
  • Supported internet protocols ARP, ICMP,
    IGMP, UDP/IP, TCP/IP, DHCP and Auto IP

KNX

  • Medium TP
  • KNXnet / IP tunneling
  • Long Frame
  • KNX IP Security (AES-128)
  • Tunneling V2, Core V2
  • Up to 8 connections at the same time

Power supply

  • From KNX Bus, approx. 20 mA

Connectors

  • KNX Bus connector
  • LAN RJ-45 socket
